LED Parking Garage is designed a beam spread from 0 to 170 degrees to reach the edge of the drive-through gas pump structures at service stations. Heat and shock resistant. Energy Savings of as much as 90% than traditional lighting. Free of maintenance.
| Spec Sheet | Parking Garage light Spec Sheet |
|---|---|
| Instruction Manual | Parking Garage light Manual |
| IES Files | Parking Garage light IES Files |
| Tech Info | Parking Garage light Tech Info |
| Model number | Voltage(V) | Wattage(W) | Replaces/Equiv.(MH) | Dimming / Control | Lumens(lm) | CCT(K) | CRI | Beam Angle(Degree) | Dimension(L”-W”-H”) | Finish/Color | IP Rating | Material | Compliance | Average life based on 104F(HRS) | Order number |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ABPKG40LED50 | 120-277 | 38 | 150W | Available | 4000 | 5000 | >70 | 120 | 12.4-12.4-9.06 | Traditional Bronze | 65 | A380 | DLC/ETL | 50000 | 10130 |
| ABPKG40LED50-PC12 | 120 | 38 | 150W | Available | 4000 | 5000 | >70 | 120 | 12.4-12.4-9.06 | Traditional Bronze | 65 | A380 | DLC/ETL | 50000 | 10779 |
| ABBPKG55501 | 120-277 | 52 | 250W | Available | 5400 | 5000 | >70 | 120 | 12.4-12.4-9.06 | Traditional Bronze | 65 | A380 | DLC/ETL | 50000 | 10133 |
| ABBPKG70501 | 120-277 | 70 | 350W | Available | 6600 | 5000 | >70 | 120 | 12.4-12.4-9.06 | Traditional Bronze | 65 | A380 | DLC/ETL | 50000 | 10135 |
